High Quality –Scoring: Accurate sheet registration, scoring and folding. In-line plow fold mechanism eliminates unnecessary folding steps.
–Stitching: The folded sets are jogged from the head and foot, then centered on the saddle by the centering mechanism before the heavy-duty stitching heads produce accurately stitched booklets.
- Trimming: Precision automated knife positioning and in-feed provides for accurate booklet registration and three-knife trimming.
Variable Data Handling – Personalized and variable page count applications can be handled. The in-line confi guration insures sheet-to-sheet integrity.
Flexible Insertion –An intelligent cover feeder enables fl exible insertion of up to 5 sheets plus cover anywhere in the booklet.
Easy Operation – Easy and intuitive operation is achieved with touch screen control. No specialized operator skills are needed to set up and operate the system.
| Model | StitchLiner6000 Digital |
|---|---|
| Sheet Size | Width x Length Max. 500 x 350 mmor 19.68” x 13.77” Min. 279.4 x 210 mmor 11.0” x 8.27” |
| Sheet Weight Range | Normal Paper : 52 to 209 gsm Coated Paper : 73 to 209 gsm |
| Stitch Thickness | Max. 5 mmor 0.19” (Booklet thickness 10 mmor 0.39”) For loop stitching, Max. 3 mmor 0.11” of booklet thickness. Min. Two Sheets (When doing center-cuts, the width is limited to half of the center-cut width.) |
| Finished Booklet Size | Width x Length Max. 340 x 230 mmor 13.38” x 9.05” Min. 160 x 114.7 mmor 6.30” x 4.52” |
| Sheet Stack Height | Max. 30 mmor 1.18” Sheets can be loaded while running. |
| Production Speed | Max. 6,000 booklets per hour (A3, one block, up to 6 sheets) Min. 2,400 booklets per hour (A3, 12 sheets, two block) |
